X11SPH-nCTPF ATX Motherboard, Scalable CPU, Single Socket, 10G SFP+, Broadcom 3008

£372.82 (ex. VAT)

Brand: Supermicro
Product Code: MBD-X11SPH-nCTPF
Condition: Refurbished
Availability: 2

X11SPH-nCTPF ATX Motherboard, Scalable CPU, Single Socket, 10G SFP+, Broadcom 3008

Supermicro Fully Featured Single Socket Scalable CPU motherboard with NVME, M.2 and Broadcom 3008 HBA controller included.

Key Features

2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors, Single Socket LGA-3647 (Socket P) supported, CPU TDP supports Up to 205W TDP
Intel® C622 chipset
Up to 2TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 2TB 3DS ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots
Expansion slots:
1 PCI-E 3.0 x16 (x16 || x8),
1 PCI-E 3.0 x8 (x0 || x8),
1 PCI-E 3.0 x8,
1 PCI-E 3.0 x4 (in x8)
2x Port NVMe PCI-E 3.0 x4 via OCuLink
M.2 NGFF connector
M.2 Interface: PCI-E 3.0 x4 and SATA
Form Factor: 2280
Key: M-Key
Double Height Connector
8 SAS3 (12Gbps) via Broadcom® 3008; RAID 0, 1, 10
10 SATA3 (6Gbps) via C622
2 10G SFP+
5 USB 3.0 (2 rear, 1 Type-A, 2 via header), 8 USB 2.0 (2 rear, 6 via headers)
